Pneumatic Grapnel Launcher Components

Pneumatic Grapnel Launcher Components

In addition to purchasing the grapnel launcher sets we understand that items can be broken or lost as well as different units have different requirements in terms of quantity. Its is therefore possible to purchase spare or replacements on an ongoing basis.

OTL63-001 - Launcher

5.00 kg (11.02 lbs)

OTL63-002 - 500cc Air Cylinder and Valve

0.90 kg (1.98 lbs)

OTL63-003 Side Mount Canister

0.72 kg (1.59 lbs)

OTL63-004 Underslung Rope Canister

1.52 kg (3.35 lbs)

OTL63-005 External Fixed Grapnel

1.32 kg (2.91 lbs)

OTL63-006 External Fixed Grapnel Projectile Rod

0.62 kg (1.37 lbs)

OTL63-007 Mark 3 Folding Grapnel Complete

1.32 kg (2.91 lbs)

OTL63-008 Messenger Line Projectile Base

0.62 kg (1.37 lbs)

OTL63-009 Messenger Line Projectile

0.62 kg (1.37 lbs)

OTL63-010 Plastic Projectile Base

0.41 kg (0.90 lbs)

OTL63-011 35m x 11mm Rope Set

3.29 kg (7.25 lbs)

FLS.15 Fibrelight 15m Ladder

2.10 kg (4.63 lbs)

FLS.20 Fibrelight 20m Ladder

2.80 kg (6.17 lbs)

OTL63-012 Loading Rod

0.31 kg (0.68 lbs)

OTL63-013 Charging Kit

2.12 kg (4.67 lbs)

OTL63-014 Rubber Band Set 50 Pieces

80 g (2.82 oz)

OTL63-015 Replacement O-Ring Kit

40 g (1.4 oz)

OTL63-016 Silicon Grease

110 g (3.9 oz)

OTL63-017 Bottle Pressure Test Gauge

0.27 kg (0.61 lbs)

OTL63-018 Dump Valve Screw

54 g (1.9 oz)

OTL63-019 Charge Valve Poppet

8 g (0.2 oz)

OTL63-020 Peli Case with Interior Foam for SF Kit

19.97 kg (44.03 lbs)

OTL63-021 Launcher Carry Sling

0.14 kg (0.31 lbs)

OTL63-022 Soft Carry Bag / Backpack

1.65 kg (3.65 lbs)

OTL63-023 Maintenance Kit in Peli Case

3.29 kg (7.25 lbs)

OTL63-026 Peli Case with Interior Foam for TAC Kit

16.00 kg (35.27 lbs)

OTL63-027 45m x 9mm Rope Set

1.69 kg (3.73 lbs)
